Power House 12V9AH Sealed Rechargeable Battery

Long 12V 9AH Rechargeable Sealed Lead Acid Battery

Nominal Voltage (V)

12V

Nominal Power

15 mins rate: 36W/cell to 1.60V/cell

5 hour rate

(1.53A to 10.20V) 7.65Ah

1 C

(9A to 9.60V) 5.7Ah

3 C

(27A to 9.60V) 3.6Ah

Weight

Approx. 2.7kg(5.94Lbs.)

Dimensions

Length (L)

151±1 (5.94±0.04)

Width (W)

65±1 (2.56±0.04)

Height (H)

94±1 (3.70±0.04)

Overall Height (HT)

102±1 (4.02±0.04)

Internal Resistance (at 1KHz)

Approx. 14 mΩ

Maximum Discharge Current for

5 seconds: 135A

Charging Methods at 25℃(77℉)

Cycle use:

Charging Voltage

Coefficient -5.0mV/℃/cell

14.4 to 15.0V

Maximum Charging Current：

2.7A

Standby use:

Float Charging Voltage Coefficient -3.0mV/℃/cell

13.5 to 13.8V

Operating Temperature Range

Charge

-15℃(5℉) to 40℃(104℉)

Discharge

-15℃(5℉) to 50℃(122℉)

Storage

-15℃(5℉) to 40℃(104℉)

Charge Retention (shelf life) at 20℃(68F)

1 month

92％

3 month

90%

6 month

80%

Case Material

ABS UL94 HB

Option: Flammability resistance of (UL94 V-0)

Design Life

3-5 Years.

Terminal

F1 or F2 (Faston Tab 187 or 250)
